Oracle Database 23ai 新功能技術介紹- 系列(三) – AI Vector Search

mkdir -p /opt/oracle/models

cd /opt/oracle/models/

wget https://adwc4pm.objectstorage.us-ashburn-1.oci.customer-oci.com/p/VBRD9P8ZFWkKvnfhrWxkpPe8K03-JIoM5h_8EJyJcpE80c108fuUjg7R5L5O7mMZ/n/adwc4pm/b/OML-Resources/o/all_MiniLM_L12_v2_augmented.zip

unzip -oq all_MiniLM_L12_v2_augmented.zip

sqlplus sys/"1qaz2wsx#EDC"@localhost:1521/freepdb1 as sysdba

create user if not exists testuser1 identified by testuser1 quota unlimited on users;

grant create session, db_developer_role, create mining model to testuser1;

create or replace directory model_dir as '/opt/oracle/models';

grant read, write on directory model_dir to testuser1;

begin

  dbms_vector.drop_onnx_model (

    model_name => 'ALL_MINILM_L12_V2',

    force => true);

  dbms_vector.load_onnx_model (

    directory  => 'model_dir',

    file_name  => 'all_MiniLM_L12_v2.onnx',

    model_name => 'ALL_MINILM_L12_V2');

end;

/

column model_name format a30

column algorithm format a10

column mining_function format a15

select model_name, algorithm, mining_function

from   user_mining_models

where  model_name = 'ALL_MINILM_L12_V2';

MODEL_NAME        ALGORITHM  MINING_FUNCTION

------------------------------ ---------------  ---------------

ALL_MINILM_L12_V2   ONNX       EMBEDDING

set long 1000000

select vector_embedding(all_minilm_l12_v2 using 'Quick test' as data) AS my_vector;

MY_VECTOR

--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

[-3.86444256E-002,7.27762803E-002,-6.99377712E-003,-7.29618035E-003,8.81512091E-003,-6.36086613E-002,4.39666817E-003,-4.20215651E-002,-1.32307202E-001,-5.83761605E-003,-1.3236966E-002,-1.62914731E-002

,6.54898351E-003,-4.983522E-002,-1.98450536E-002,-4.69920225E-002,1.03937663E-001,-8.96753445E-002,-2.77861813E-003,4.13947664E-002,-6.51626661E-002,-1.09901905E-001,-8.73053819E-003,2.533352E-002,-1.

42030632E-002,-2.42071245E-002,1.91591978E-002,4.93748812E-003,6.30869251E-003,-1.24127813E-001,-7.17297941E-003,3.7317384E-002,4.97635901E-002,4.52162437E-002,1.49683114E-002,-2.21795831E-002,-3.6793

6082E-002,-6.20233943E-004,7.16803819E-002,5.33913262E-003,1.92087106E-002,-9.91346017E-002,3.90679464E-002,2.22725421E-002,5.04363105E-002,1.81943253E-002,5.34031466E-002,1.44161871E-002,-1.99907795E

-002,-1.20323608E-002,-2.63888389E-002,-4.14667316E-002,6.2473774E-002,-4.68838662E-002,1.16748568E-002,-2.43180972E-002,-3.11982706E-002,-7.5750039E-003,2.25466359E-002,-4.17359956E-002,1.23237111E-0

02,4.31706831E-002,-7.83750787E-002,1.24918511E-002,5.42060807E-002,4.33742851E-002,2.52278382E-003,-1.15482137E-002,-9.98658361E-004,-2.12613102E-002,1.00960173E-002,3.17986645E-002,-1.13146752E-002,

-1.26893371E-002,2.66182758E-002,-7.50683714E-003,-3.70341949E-002,1.94851588E-002,-2.9213747E-002,-2.61210538E-002,2.86212545E-002,-9.15900841E-002,1.50552345E-002,-4.98168021E-002,2.29324233E-002,7.

82517716E-003,4.22972552E-002,3.37974802E-002,-4.2345725E-002,-6.32970557E-002,3.84949856E-002,-1.93851739E-002,1.96233811E-003,-3.91593436E-004,7.80334743E-003,5.63595518E-002,4.45814878E-002,-4.9701

6348E-002,1.36384079E-002,2.76547611E-001,6.3580215E-002,-1.69337653E-002,-3.25948671E-002,2.74621621E-002,-1.84809547E-002,-3.58916223E-002,3.18280957E-003,-3.92074026E-002,-5.03925188E-003,-3.951984

27E-002,2.64224112E-002,5.44404946E-002,-2.97634304E-003,1.06564369E-002,4.55005467E-002,-9.6166715E-002,4.53019142E-002,3.02239861E-002,-1.11025631E-001,6.18582554E-002,8.55141804E-002,-1.51456865E-0

02,-5.64082488E-002,-5.93042118E-004,1.07500188E-001,-6.81523383E-002,1.85917299E-002,3.75312977E-002,-3.27163041E-002,-4.72422279E-002,5.59753366E-002,2.20437758E-002,2.74991542E-002,2.6306238E-002,-

MY_VECTOR

--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

5.36229946E-002,6.86868653E-003,5.06033236E-003,8.8686645E-002,3.97679023E-002,-1.49526203E-003,-1.11991554E-001,-1.48920557E-002,-1.42183565E-002,5.44682518E-002,-5.46902828E-002,-3.37714851E-002,-3.

93099487E-002,-8.88748933E-003,-2.50034276E-002,-3.86718176E-002,7.15422928E-002,-1.72947664E-002,5.7217218E-002,1.23445597E-002,-6.2534079E-002,-1.97963249E-002,4.08163741E-002,9.22357664E-003,2.3645

6636E-002,-4.27602604E-003,-1.24366455E-001,8.28649253E-002,-5.27119003E-002,-1.11121042E-002,4.35752422E-002,1.35777146E-002,-2.25060452E-002,4.55260389E-002,3.8973894E-002,-8.93306658E-002,1.1729340

3E-001,5.51190414E-002,-2.56631672E-002,-5.30632474E-002,-8.3953537E-002,4.83216904E-003,6.57674596E-002,8.87271464E-002,-1.52742835E-002,1.0525425E-002,-1.5814418E-002,-3.10783181E-002,-2.90690996E-0

02,7.04224128E-003,-3.09849493E-002,-4.46302071E-003,-7.20088482E-002,-7.05658421E-002,4.65546139E-002,1.10276654E-001,3.60872261E-002,1.86069943E-002,-6.10642694E-002,3.21829356E-002,-1.43657662E-002

,-6.75653145E-002,8.0748558E-002,1.68782603E-002,-1.0059043E-001,-7.55800977E-002,-1.69591643E-002,-4.4571083E-002,-8.6054299E-003,4.3378789E-002,4.29520719E-002,3.94066535E-002,8.67496245E-003,-8.521

2335E-002,1.20206423E-001,-1.14268221E-001,-1.7028559E-002,8.87670461E-003,-4.69081141E-002,-3.02138384E-002,4.61057387E-002,-4.92519997E-002,1.5618098E-002,-9.27053913E-002,-6.08293712E-002,1.4645159

2E-002,-1.84691269E-002,-1.40407518E-001,5.35490997E-002,5.85880894E-033,7.62652457E-002,-3.07706036E-002,-6.74770074E-003,1.03074081E-001,7.20860362E-002,-9.75818709E-002,1.51840553E-001,7.43321329E-

002,-2.99238227E-002,9.39517915E-002,1.50299724E-002,4.35530096E-002,-7.5808214E-003,-7.49262646E-002,-5.07647395E-002,4.01099063E-002,-7.43360221E-002,4.62087579E-002,9.61421523E-003,3.15185694E-004,

6.20259941E-002,1.57011077E-002,3.29307318E-002,5.69748059E-002,-7.89974183E-002,9.78372246E-003,1.16776042E-002,-3.65987606E-002,-5.30387387E-002,-1.22491773E-002,5.65313101E-002,3.41438241E-002,-4.2

6849052E-002,9.84478816E-002,1.52461289E-003,-6.92429617E-002,9.64930356E-002,-1.85021386E-002,4.28027324E-002,-4.41830754E-002,-2.54553296E-002,5.20384498E-002,-1.38082858E-002,-1.59469545E-002,2.100

MY_VECTOR

--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

03126E-002,-1.85695048E-002,2.29395889E-002,1.91418324E-002,4.09490801E-002,2.35137548E-002,-3.91654707E-002,3.57466713E-002,4.80409227E-002,-1.02699148E-002,1.45040629E-002,-4.27465364E-002,-5.092588

44E-002,-7.12790638E-002,-9.19121876E-002,1.79740377E-002,-3.53490934E-002,-2.26370133E-002,1.6497435E-002,1.05952598E-001,-3.52565758E-002,-3.41151431E-002,-5.7282865E-002,-3.10265832E-002,6.97579682

E-002,-2.50360705E-002,-3.91423441E-002,1.37532474E-002,6.76135859E-003,-5.15896529E-002,-3.55789214E-002,6.91288933E-002,-3.4734223E-002,-1.098355E-002,-2.45214198E-002,-3.24611887E-002,1.08489497E-0

02,8.21795501E-003,-2.97738295E-002,4.81432006E-002,-5.78631125E-002,2.8562462E-002,4.02920581E-002,2.82907318E-002,-3.79493348E-002,8.59354064E-003,1.02058174E-002,2.48055868E-002,7.16195162E-003,-6.

24535196E-002,-3.25725861E-002,4.26037687E-033,-7.57265091E-003,-4.15650047E-002,-4.9813509E-002,1.02479653E-002,3.28872614E-002,1.50397036E-003,-6.39198944E-002,-7.53579438E-002,-2.46183965E-002,-3.0

6450091E-002,4.16100211E-002,7.04020783E-002,-8.15085769E-002,2.55300757E-002,1.89818796E-002,4.26408388E-002,-2.19986811E-002,7.13623175E-003,-3.42554823E-002,3.70062445E-003,-3.15255509E-003,1.41580

394E-002,5.00133969E-002,7.54985511E-002,6.42605647E-002,7.55612105E-002,1.52721936E-002,1.15661152E-001,-2.45987345E-002,1.08358106E-002,5.02406769E-002,6.28810748E-002,-5.52952401E-002,-5.5196926E-0

02,-4.60026506E-003,-1.46539938E-002,6.40283972E-002,5.18338159E-002,2.51765456E-002,6.45218045E-002,-8.35603252E-002,3.57579924E-002,6.28178008E-003,3.15947039E-003,2.320843E-002,4.76812162E-002,-5.4

7788292E-003,-1.06323622E-001,-1.45862857E-002,-5.92180677E-002,-1.59236323E-002,-1.90922078E-002,4.61261906E-002,2.41158754E-002,-7.90221989E-003,1.11448206E-001,1.11205513E-002,-2.0573806E-002,-4.08

658385E-002,5.5462148E-002,5.37177995E-002,4.76263314E-002,-3.29908058E-002,4.37314026E-002]

cd /opt/oracle/models/

wget https://huggingface.co/datasets/ygorgeurts/movie-quotes/resolve/main/movie_quotes.csv?download=true -O movie_quotes.csv

sqlplus testuser1/testuser1@localhost:1521/freepdb1

drop table if exists movie_quotes purge;

create table movie_quotes as

select movie_quote, movie, movie_type, movie_year

from   external (

         (

           movie_quote  varchar2(400),

           movie        varchar2(200),

           movie_type   varchar2(50),

           movie_year   number(4)

         )

         type oracle_loader

         default directory model_dir

         access parameters (

           records delimited by newline

           skip 1

           badfile model_dir

           logfile model_dir:'moview_quotes_ext_tab_%a_%p.log'

           discardfile model_dir

           fields csv with embedded terminated by ',' optionally enclosed by '"'

           missing field values are null

           (

             movie_quote char(400),

             movie,

             movie_type,

             movie_year

           )

        )

        location ('movie_quotes.csv')

        reject limit unlimited

      );

alter table movie_quotes add (

  movie_quote_vector vector

);

SQL> desc movie_quotes

 Name                       Null?  Type

 ----------------------------------------- -------- ----------------------------

 MOVIE_QUOTE                     VARCHAR2(400)

 MOVIE                            VARCHAR2(200)

 MOVIE_TYPE                       VARCHAR2(50)

 MOVIE_YEAR                       NUMBER(4)

 MOVIE_QUOTE_VECTOR             VECTOR(*, *)

update movie_quotes

set    movie_quote_vector = vector_embedding(all_minilm_l12_v2 using movie_quote as data);

commit;

variable search_text varchar2(100);

exec :search_text := 'Films with motivational speaking in them';

set linesize 200

column movie format a50

column movie_quote format a100

SELECT vector_distance(movie_quote_vector, (vector_embedding(all_minilm_l12_v2 using :search_text as data))) as distance,

       movie,

       movie_quote

FROM   movie_quotes

order by 1

fetch approximate first 5 rows only;

  DISTANCE MOVIE                        MOVIE_QUOTE

---------- -------------------------------------------------- ----------------------------------------------------------------------------------------------------

6.786E-001 Once Upon a Time in Hollywood   That was the best acting i've ever seen in my whole life.

6.979E-001 Dead Poets Society              You must strive to find your own voice because the longer you wait to begin, the less likely you are

                                         going to find it at all.

7.169E-001 The Pursuit of Happyness        Walk that walk and go forward all the time. Don't just talk that talk, walk it and go forward. Also,

                                        the walk didn't have to be long strides; baby steps counted too. Go forward.

7.186E-001 Joker                         My mother always tells me to smile and put on a happy face. She told me I had a purpose to bring lau

                                        ghter and joy to the world.

7.234E-001 Blazing Saddles               Men, you are about to embark on a great crusade to stamp out runaway decency in the west. Now you me

  DISTANCE MOVIE                      MOVIE_QUOTE

---------- -------------------------------------------------- ----------------------------------------------------------------------------------------------------

                                       n will only be risking your lives, whilst I will be risking an almost certain Academy Award nominati

                                       on for Best Supporting Actor.

variable search_text varchar2(100);

exec :search_text := 'Films about war';

set linesize 200

column movie format a50

column movie_quote format a100

SELECT vector_distance(movie_quote_vector, (vector_embedding(all_minilm_l12_v2 using :search_text as data))) as distance,

       movie,

       movie_quote

FROM   movie_quotes

order by 1

fetch approximate first 5 rows only;

  DISTANCE MOVIE                   MOVIE_QUOTE

---------- -------------------------------------------------- ----------------------------------------------------------------------------------------------------

5.682E-001 Dr. Strangelove             Gentlemen, you can't fight in here! This is the War Room!

6.346E-001 Blazing Saddles            Men, you are about to embark on a great crusade to stamp out runaway decency in the west. Now you me

                                    n will only be risking your lives, whilst I will be risking an almost certain Academy Award nominati

                                    on for Best Supporting Actor.

6.587E-001 Fury                      Ideals are peaceful; history is violent.

7.243E-001 The Kill Team              You give me your loyalty, and I?ll guarantee that each and every one of you will have a chance to be

                                    a warrior, to actually be a part of history.

7.253E-001 Dr. No                    Bond. James Bond
